GRAF Ecobloc Flex Stormwater Block

Graf Eco Bloc Flex Modular Rainwater Detention Solution at BARR PLastics

GRAF Ecobloc Flex Stormwater Block

Web Id: 402005

The GRAF EcoBloc Flex is a versatile system, able to be used for stormwater infiltration, retention or rainwater harvesting. Shipping is cost-efficient, as the modular system’s two halves can be stacked, one inside the other.Even under very heavy loads, the EcoBloc system can be installed at a depth of up to 16.5 feet. Up to 14 layers are possible and the system can withstand a capacity of 60 tons. Note: the system size and load bearing can be adjusted individually to suit requirements of traffic and non-traffic areas. Designed to have high rate of percolation and barrier-free inspection,the EcoBloc has 4", 6" and 8" connections on all sides. 4" connections are positioned eccentrically at the side for complete de-aeration The system is easily cleaned by pressure washing and designed for a service life of over 50 years

Are you an engineer or designer?

Contact us (via our contact form or by phone) for technical specification and system design documentation to integrate Ecobloc into your stormwater drainage plan!

Swipe over the table to view all of the columns
Click on Part # to view technical drawing
Part # / Model Size Description Weight (lbs)
40200531" x 31" x 12"
GRAF EcoBloc Flex (1 Module)(55 USG / 205L)17.6
40200631" x 31" x 1.5"GRAF EcoBloc Baseplate (6.6 USG / 25 L)N/A
402002N/AGRAF EcoBloc End Plates (Set of 2)N/A
402028N/AGRAF EcoBloc Connectors (Set of 25)N/A
369017Deaeration EndN/A
